Ready-to-weld Roll Cage Kit for Polaris® RZR XP4 1000 / XP Turbo (2014-2018)
High quality DOM steel used throughout. Main tubes are 1.75 diameter .095 thick and cross tubes are 1.5 diameter and .095 thick. Our Baja Spec use all stock mounting locations. Trophy Truck inspired design provides exceptional safety for driver and co-rider. All tubes are mandrel bent and laser cut for exact fit. No grinding or other work required. Kit can be assembled and welded on chassis without the need for a separate fixture. This kit meets SCORE and Best in the Desert roll cage requirement in terms of material, tube size, and design. Please check with the rule books for complete safety requirements.
*ROOF NOT INCLUDED IN KIT.
*In order to retain stock doors, front door hinges must be removed from stock cage and re-welded to our cage. Doors will retain exact stock location and fit.
What's In The Box?
- 22 Laser Notched Tubes with tab and slot design for easy positioning of tubes
- 6 Billet Tube Ends (chassis clamps)
- 4 Chassis Mount Plates
- 2 Rear Door Latch Mount Plates
Technical Specifications
- Highest grade DOM 1020 steel
- Main tubes 1.75 diameter / Interior tubes 1.5
- All tubes .095 wall thickness
- (6) CNC Machined chassis clamps included
- (4) Mounting plates for front row / back row tubes included
- Highly triangulated roll cage for added strength
- Tubes are laser cut and labeled
- Flat roof design
- No welding fixture required. Can be welded using the vehicle as the fixture
- No grinding or other fab work required
- Competent welder and welding machine, tape measure and 2 ratchet straps are all that is required
- Kit can be TIG or MIG welded
