Ready-to-weld Super Shorty Roll Cage Kit for Polaris® RZR Pro R (2022+).
High quality DOM steel used throughout. Main tubes (rolled roof tube and B-Pillar) are 1.75 diameter .120 wall thickness, rear intrusion tubes are 1.5 diameter .095 wall thickness, front intrusion tubes are 1.25 diameter .095 wall thickness, all remaining tubes are 1.75 diameter .095 wall thickness. Our Super Shorty roll cages use all stock mounting locations. Trophy Truck inspired design provides exceptional safety for driver and co-rider. This is truly the best roll cage kit on the market. All tubes are mandrel bent and laser cut for exact fit. No grinding or other work required. Kit can be assembled and welded on chassis without the need for a separate fixture.
Specifications
- Highest grade 1020 DOM steel
- 1.75 x .120 main tubes
- 1.75 x .095 internal tubes
- 1.5 x .095 rear intrusion tubes
- 1.25 x .095 front intrusion tubes
- .7 shorter in overall height
- (6) CNC Machined chassis clamps included
- Highly triangulated roll cage for added strength
- Slight radius roof design used
- Tubes are laser cut and labeled
- No welding fixture required
- No grinding or other fab work required
- Competent welder and welding machine, tape measure and ratchet straps are all that is required
- Kit can be TIG or MIG welded
